GM International D1022D Loop Powered Current Repeater DIN-Rail

GM International D1022D Loop Powered Current Repeater DIN-Rail

Artikelnummer: GMI20250031
Hersteller: GM International

295,00 €

exkl. 19% USt. , zzgl. (National)

Sofort verfügbar
Lieferzeit: 3 - 5 Werktage (Ausland)

Beschreibung

FEATURES

Output to Zone 0 (Zone 20), Division 1, installation in Zone 2, Division 2.
High Density, two channels per unit.
Wide operating current range from 1 to 40 mA.
Field open circuit detection.
Input/Output isolation
EMC Compatibility to EN61000-6-2, EN61000-6-4.
250 Vrms (Um) max. voltage allowed to the instruments associated with the barrier.

Technical Data

Supply
Voltage	No supply voltage required because loop-powered.
Power Dissipation	≤ 1.1 W per channel at 40 mA, 30 V loop supply.
Output
Type	1 to 40 mA.
Output characteristic (typical)	Vout = (Vin - 1.5) - (0.4 x Iout) for 6 V < Vin < 23 V. Vout = 22 - (0.4 x Iout) for 23 V < Vin < 30 V. 4-20 mA output on load of 100 to 600 Ω; Accuracy ≤ 1 %.
Response time	50 ms (10 to 90 % step change).
Input
Range	6 to 30 V (loop powered).
Input current	1 to 40 mA (loop powered)
Voltage drop-out	9.5 V at 20 mA and with 500 Ω load.
Open circuit consumption	≤ 0.4 mA at 20 V
Performance
Reference ambient temperature conditions	23 ± 1 °C.
Current transfer error	≤ 400 µA (6 V
Temperature influence	≤ ± 0.01 % for a 1 °C change.
Isolation
Test Voltage	I.S. Out/In 1.5 KV; I.S. Out/I.S. Out 500 V; In/In 500 V.
Environmental conditions
Operating	temperature limits -20 to + 60 °C,relative humidity max 90 % non condensing, up to 35 °C.
Storage	temperature limits – 45 to + 80 °C.
Safety description
Safety parameters	Uo/Voc = 25.2 V, Io/Isc = 93 mA, Po/Po = 581 mW at terminals 13-14, 15-16. Um = 250 Vrms, -20 °C ≤ Ta ≤ 60 °C.
Mounting
Type	EN/IEC60715 TH 35 DIN-Rail.
Weight	about 125 g
Connection	by polarized plug-in disconnect screw terminal blocks to accomodate terminations up to 2.5 mm².
Location	Safe Area/Non Hazardous Locations or Zone 2, Group IIC T4, Class I, Division 2, Groups A, B, C, D Temperature Code T4 and Class I, Zone 2, Group IIC, IIB, IIA T4 installation.
Protection class	IP 20.
Dimensions	Width 22.5 mm, Depth 99 mm, Height 114.5 mm.

Versandgewicht:	0,50 kg
Artikelgewicht:	0,30 kg
Abmessungen ( Länge × Breite × Höhe ):	16,00 × 14,00 × 14,00 cm
Zustand / Condition:	Neu / New
