Electrical data:
Nominal voltage - 24 V DC
Short-term permissible voltage range - 19 to 26 V DC
Current consumption* - CentralControl/GatewayControl: approx. 0.15 A
SegmentControl/ComControl: approx. 0.05 A + connected sensors and actuators
Nominal current per RollerDrive: approx. 2 A
Starting current per RollerDrive: approx. 4 A
Fuse - Present, non-replaceable
Protection class - IP54
Functions:
·Logic for backpressure-free conveying, including initialization
·Communication via bus system
·Configurator allows setting of (individually, in groups, or all participants):
–Speed, direction of rotation, start and stop ramp of the RollerDrive
–Sensor properties
–Timer
–Error handling
–Logic for single-position/block removal
·Status display via LEDs
·Additional functions:
–Emptying the conveyor
–External start or stop signal
·Interface to PROFIBUS, PROFINET, or EtherNet/IP
·Voltage limitation via brake chopper
·Plug & play in case of replacement - no addressing or configuration necessary
| Shipping weight: |
0,90 kg
|
| Item weight: |
0,50 kg
|
| Dimensions
( Length × Width × Height ):
|
30,00 × 10,00 × 10,00 cm |
| Zustand / Condition: |
Ungebraucht in OVP / Unused in box |
Product safety information
Manufacturer information:
Interroll
Via Gorelle 3
Tessin
Sant'Antonino, Schweiz, 6592
de.sales@interroll.com
https://www.interroll.com
Important Notice!
Our items are generally not new. They come from inventory liquidations and dismantlings.
Please note that for items where no age information is provided in the description, it should be assumed that they have been stored for a very long time, possibly several years. This can affect the quality and durability of technical items. Please consider this before making a purchase.
