Shaft length: 110mm
Outer shaft diameter: 48 mm (without groove)
Outer shaft diameter: 53 mm (with groove)
Inner diameter: 17 mm (without thread)
Inner diameter: 15 mm (with thread)
3-MOT 1CV2184D 1LE15011ED434FB4-Z UD 1708/1956034-001-001
EC/EN 60034 180L IMB5 IP55
Th.Cl. 155(F) -20° C <=TAMB<=40° C
Bearing
DE 6210-ZC3
NE 6210-ZC3
440V 50Hz 26A 11kW 0.7PF 66,9NOM.EFF 720rpm IE2 IE-CL
460V 60Hz 25.5A 13.2kW 0.73PF 68,5NOM.EFF 865rpm IE1 IE-CL
460V 60Hz 22.5A 11kW 0.69PF 68,5NOM.EFF 875rpm IE2 IE-CL
| Shipping weight: |
178,00 kg
|
| Item weight: |
166,00 kg
|
| Dimensions
( Length × Width × Height ):
|
74,00 × 40,00 × 60,00 cm |
| Zustand / Condition: |
Ungebraucht / Unused |
