Rated continuous power (W) at Ta ~40 °C: 100 W
Resistance values at 20 °C: 20 Ω, 40 Ω, 50 Ω, 68 Ω, 80 Ω, 100 Ω, 135 Ω, 270 Ω
Resistance tolerance at 20 °C: ±10 %
Protection class (EN 60529): IP 65
Maximum permissible operating voltage UL: 1000 V / CE 1000 VDC
Cooling: Natural convection
Housing temperature at rated continuous power
Ta ~ 40 °C: ~ 250 °C
Thermal switch trip temperature: 200 °C
Minimum clearance to other devices: >20 mm
Electrical connection: 2 x AWG 14 / L = 50 cm
Operating temperature range: -25 ... +40 °C
Test voltage: 2.7 kV AC (1 s)
| Item information |
Value |
| Shipping weight: |
0,40 kg
|
| Item weight: |
0,30 kg
|
| Dimensions
( Length × Width × Height ):
|
16,00 × 14,00 × 14,00 cm |
| Zustand / Condition: |
Versiegelt Ungebraucht / Sealed Unused |
Product safety information
Manufacturer information:
Nidec Deutschland GmbH
Meysstrasse 20
Nordrhein-Westfalen
Hennef, Deutschland, 53773
info.de@mail.nidec.com
https://acim.nidec.com
Important Notice!
Our items are generally not new. They come from inventory liquidations and dismantlings.
Please note that for items where no age information is provided in the description, it should be assumed that they have been stored for a very long time, possibly several years. This can affect the quality and durability of technical items. Please consider this before making a purchase.
