Primary current in A: 1000
Secondary current in A: 5
Apparent power (VA): 15
Accuracy class: 1
---------------------------
Dimensions:
Rail 1 in mm: 80x10/60x30
Busbar 2 in mm: 2x60x10
Round conductor in mm: 55
Width in mm: 120
Height in mm: 123.5
Total depth in mm: 58
-----------------------
Technical Data:
Rated continuous current Icth: 1.0 x Ipr
Rated short-time current Ith: 60 x Ipr, 1 sec.
Operating voltage Um: 0.72 kV
Insulation test voltage: 3 kV, Ueff, 50 Hz, 1 min.
Rated frequency: 50/60 Hz
| Item information |
Value |
| Shipping weight: |
1,00 kg
|
| Item weight: |
0,60 kg
|
| Dimensions
( Length × Width × Height ):
|
16,00 × 14,00 × 14,00 cm |
| Zustand / Condition: |
Ungebraucht / Unused |
Product safety information
Manufacturer information:
MBS
Eisbachstraße 51
Baden-Württemberg
Sulzbach-Laufen, Deutschland, 74429
info@mbs-ag.com
https://mbs-ag.com
Important Notice!
Our items are generally not new. They come from inventory liquidations and dismantlings.
Please note that for items where no age information is provided in the description, it should be assumed that they have been stored for a very long time, possibly several years. This can affect the quality and durability of technical items. Please consider this before making a purchase.
