Using the appropriate collar flanges, the clamp flange can be connected to various fixed bolted flange systems (ISO-F, DIN EN 1092-1, etc.); see the illustrations in the chapter “ISO-F and DIN EN 1092-1 Fixed Flange Fittings”. The clamp flange connection (according to DIN 28 404 and ISO 1609) allows components from DN 63 to DN 630 to be connected in any position, regardless of the arrangement of the bolt holes on fixed flanges. It consists of two clamp flange components (1), a centering ring (2) with an outer ring that encloses the O-ring seal, and several clamps (3) used to assemble and tighten the Connection. Since the centering ring can be firmly inserted into the centering groove of the flange, even horizontal connections can be assembled quickly and easily.
| Item information |
Value |
| Shipping weight: |
0,50 kg
|
| Item weight: |
0,40 kg
|
| Dimensions
( Length × Width × Height ):
|
16,00 × 14,00 × 14,00 cm |
| Zustand / Condition: |
Ungebraucht / Unused |
Product safety information
Manufacturer information:
Leybold GmbH
Bonner Straße 498
Nordrhein-Westfalen
Köln, Deutschland, 50968
info@leybold.com
https://www.leybold.com
Important Notice!
Our items are generally not new. They come from inventory liquidations and dismantlings.
Please note that for items where no age information is provided in the description, it should be assumed that they have been stored for a very long time, possibly several years. This can affect the quality and durability of technical items. Please consider this before making a purchase.
