ELECTRICAL SPECIFICATIONS
Number of rings: 6, 12, 18, or 24 per system
Current (per ring): ≤ 10 A
Voltage: ≤ 500 VDC / 500 VAC
Dielectric strength: ≤ 1500 VAC at 50 Hz / 1 s
Insulation resistance: ≤ 1000 MΩ at 500 VDC
Noise: ≤ 20 mΩ at 5 min-1 at 6 VDC / 50 mA
Contacts: Silver - Silver
MECHANICAL DATA
Speed: ≤ 400 rpm
Protection class: IP 54
Operating temperature: -40 °C ... +80 °C
Connections (rotor and stator): 1000 mm strands; AWG 16 (1.23 mm²)
Bearings: Precision steel ball bearings
Housing: PC GF
Outer diameter: 104 mm
Hollow shaft diameter: 50 mm (38.1 mm with adapter)
| Item information |
Value |
| Shipping weight: |
1,20 kg
|
| Item weight: |
1,00 kg
|
| Dimensions
( Length × Width × Height ):
|
22,00 × 22,00 × 14,00 cm |
| Zustand / Condition: |
Ungebraucht / Unused |
Product safety information
Manufacturer information:
LTN Servotechnik GmbH
Georg-Hardt-Straße 4
Bayern
Otterfing, Deutschland, 83624
ltn@ltn.de
https://www.ltn-servotechnik.com
Important Notice!
Our items are generally not new. They come from inventory liquidations and dismantlings.
Please note that for items where no age information is provided in the description, it should be assumed that they have been stored for a very long time, possibly several years. This can affect the quality and durability of technical items. Please consider this before making a purchase.
