| Output Signal |
PNP Output |
| Mounting Method |
For installation in the GT2-100N/100P (up to 3 boards) |
Power Consumption
|
Normal
|
Max. 4,200 mW (at 30 V, max. 140 mA)*1 |
Power-Saving Mode (Eco)
|
Max. 4,000 mW (at 30 V, max. 133.3 mA) |
| Control input |
Clock input, preset input,
range selection, reset input
|
Voltage-free input |
|
HH/HI/GO/LO/LL
|
Open PNP collector, 30 V 50 mA or less*2, residual voltage 1 V or less |
| Response time |
hsp(3)/5/10/100/500/1,000 ms
(When using GT2-Pxxx, hsp(12)/20/40/400/2,000/4,000 MS) |
| Environmental Resistance |
Ambient Temperature |
10 to +50 °C (No Freezing) |
| Relative humidity |
35 to 85% RH (No condensation) |
| Vibration resistance |
10 to 55 Hz, peak-to-peak amplitude 1.5 mm, 2 hours each in X, Y, and Z directions |
|
Material
|
Main housing: Polycarbonate, Key surface: Polyacetal, Front panel: PET |
Power supply / I/O cable
|
E/A: 30-pin connector (MIL Standard)
|
|
Weight
|
Approximately 80 g
|
| Item information |
Value |
| Shipping weight: |
0,80 kg
|
| Item weight: |
0,20 kg
|
| Dimensions
( Length × Width × Height ):
|
21,00 × 21,00 × 13,00 cm |
| Zustand / Condition: |
Ungebraucht in OVP / Unused in box |
Product safety information
Manufacturer information:
KEYENCE DEUTSCHLAND GmbH
Siemensstraße 1
Hessen
Neu-Isenburg, Deutschland, 63263
info@keyence.de
https://www.keyence.de
Important Notice!
Our items are generally not new. They come from inventory liquidations and dismantlings.
Please note that for items where no age information is provided in the description, it should be assumed that they have been stored for a very long time, possibly several years. This can affect the quality and durability of technical items. Please consider this before making a purchase.
