FEATURES
- SIL 3 / SC 3
- Installation in Zone 2
- Installation in Div. 2
- Suitable for 2/3/4-wire transmitters
- High Density, two channels per unit
STATUS
Technical Data
Supply
|
| Voltage |
24 Vdc nom (20 to 30 Vdc), from Termination Board. |
| Current rating |
0.5 A (resettable fuse protected), with linear derating down to 0.4 A, from 25 to 70 °C. |
| Max power dissipation |
160 mW @ 400 mA. |
Input/Output
|
| Voltage rating |
30 V. |
| Current rating |
0.1 A (resettable fuse protected), with linear derating down to 0.05 A, from 25 to 70 °C. |
| Max power dissipation |
8.6 mW/17.2 mW (D6004S/D6004D) @ 24 mA,
37.5 mW/75 mW (D6004S/D6004D) @ 50 mA. |
Environmental conditions
|
| Operating temperature |
temperature limits –40 to +70 °C. |
| Storage temperature |
temperature limits –45 to +80 °C. |
Mounting
|
| Type |
On custom Term. Board. |
| Weight |
about 100 g. |
| Connection |
by polarized plug-in disconnect screw terminal blocks to accomodate terminations up to 2.5 mm² (13 AWG). |
| Dimensions |
Width 12.5 mm, Depth 123 mm, Height 120 mm. |
| Item information |
Value |
| Shipping weight: |
0,50 kg
|
| Item weight: |
0,30 kg
|
| Dimensions
( Length × Width × Height ):
|
16,00 × 14,00 × 14,00 cm |
| Zustand / Condition: |
Neu / New |
Product safety information
Manufacturer information:
G.M. International S.p.A
Via G. Mameli 53-55
Monza e Brianza
Villasanta, Italien, 20852
info@gminternational.com
https://gminternational.com/
