Contact configuration: 2 changeover contacts (DPDT / 2 CO)
Max. continuous current / Inrush current: 10 A / 20 A
Rated voltage / Max. switching voltage: 250 V AC / 400 V AC
Max. switching capacity (AC1): 2500 VA
Max. switching capacity (AC15, 230 V AC): 500 VA
Rated voltage: 24 V DC
Rated power consumption: approx. 1.0 W
Coil resistance: 600 Ω
Operating range: 19.2 V DC (min.) to 26.4 V DC (max.)
Holding voltage: 14.4 V DC
Must-release voltage (Drop-out voltage): 2.4 V DC
Ambient temperature: -40 °C to +85 °C
Operate / Release time: 11 ms / 3 ms
Dielectric strength (Coil/Contacts): 4 kV (1.2/50 µs)
Protection category: Flux proof (RT I)
| Item information |
Value |
| Shipping weight: |
0,40 kg
|
| Item weight: |
0,32 kg
|
| Dimensions
( Length × Width × Height ):
|
15,00 × 14,00 × 14,00 cm |
| Zustand / Condition: |
Ungebraucht in OVP / Unused in box |
Product safety information
Manufacturer information:
FINDER GmbH
Hans-Böckler-Str 44
Hessen
Trebur, Deutschland, 65468
https://www.findernet.com
Important Notice!
Our items are generally not new. They come from inventory liquidations and dismantlings.
Please note that for items where no age information is provided in the description, it should be assumed that they have been stored for a very long time, possibly several years. This can affect the quality and durability of technical items. Please consider this before making a purchase.
