Rated control supply voltage Us at 50 Hz AC: 24–60 V
Rated control supply voltage Us at 60 Hz AC: 24 V
Rated control supply voltage Us at DC: 20 V
Voltage type for actuation: AC/DC
Number of normally open contacts as main contacts: 3
Main circuit connection type: Screw terminals
Operating voltage at AC 50 Hz: 690 V
Operating voltage at AC 60 Hz: 690 V
Rated operating current Ie at AC-1, 400 V: 25 A
Rated operating current Ie at AC-3, 400 V: 9 A
Rated operating power at AC-3, 400 V: 4 kW; NEMA rated operating power: 1.4914 kW
Number of auxiliary normally open contacts: 1
Suitable for side-by-side mounting: No
Width: 45 mm; Height: 86 mm; Depth: 77 mm
| Shipping weight: |
0,50 kg
|
| Item weight: |
0,33 kg
|
| Dimensions
( Length × Width × Height ):
|
15,00 × 14,00 × 14,00 cm |
| Zustand / Condition: |
Ungebraucht in OVP / Unused in box |
Product safety information
Manufacturer information:
ABB AG
Kallstadter 1
Baden-Württemberg
Mannheim, Deutschland, 68309
contact.center@de.abb.com
https://new.abb.com
