Stripping Length
15 mm
Connection Type
Screw connection
Connection Direction
Side
Number of Connections
2
Tightening Torque, max.
2.64 Nm
Tightening Torque, min.
2 Nm
Clamping Range, max.
16 mm²
Clamping range, min.
2.5 mm²
Clamping screw
M 4
Max. conductor cross-section (CSA)
4 AWG
Min. conductor cross-section (CSA)
14 AWG
Voltage, Class C (CSA)
600 V
Current, Class C (CSA)
87 A
Storage temperature
-25 °C...55 °C
Ambient temperature
-50 °C…55 °C
Continuous operating temperature, min.
-50 °C
Continuous operating temperature, max.
100 °C
| Item information |
Value |
| Shipping weight: |
1,00 kg
|
| Item weight: |
0,80 kg
|
| Dimensions
( Length × Width × Height ):
|
25,00 × 19,00 × 18,00 cm |
| Zustand / Condition: |
Ungebraucht / Unused |
Product safety information
Manufacturer information:
Weidmüller GmbH & Co. KG
Klingenbergstraße 26
Nordrhein-Westfalen
Detmold, Deutschland, 32758
weidmueller@weidmueller.de
https://www.weidmueller.de
Important Notice!
Our items are generally not new. They come from inventory liquidations and dismantlings.
Please note that for items where no age information is provided in the description, it should be assumed that they have been stored for a very long time, possibly several years. This can affect the quality and durability of technical items. Please consider this before making a purchase.
