Drehzahl 50Hz [r/min] 1360 / 166
Drehzahl 60Hz [r/min] 1700 / 207
Übersetzung gesamt [i] 8,20
Ma max [Nm] 29
Abtriebsdrehmoment 50Hz [Nm] 27
Abtriebsdrehmoment 60Hz [Nm] 22
Betriebsfaktor SEW-FB 1,05 / 1,30
Bauform IM M3B
ISO-Bezeichnung SEW PG 460
Schmierstoffsorte Synth.Öl
Schmierstoffmenge [l] 0,24
Motor-Leistung [kW] 0.55 / 0.55
Einschaltdauer S1-S10 S1
Spannungsbereich 50 Hz [V] 220-242 Dreieck / 380-420 Stern
Nennstrom [A] 2,80 / 1,62
Spannungsbereich 60 Hz [V] 254-277 Dreieck / 440-480 Stern
Nennstrom [A] 2,25 / 1,31
Motor-Frequenz A [Hz] 50
Motor-Frequenz B [Hz] 60
cos phi 0,72 / 0,68
Wärmeklasse[°C]/Schutzart[IP] 130(B) / 55
International efficiency class IE1
Wirkungsgrad 50 Hz 70,6
Wirkungsgrad 60 Hz 74,0
Umgebungstemperatur min. [°C] -20
Umgebungstemperatur max. [°C] 40
| Shipping weight: |
12,00 kg
|
| Item weight: |
10,20 kg
|
| Dimensions
( Length × Width × Height ):
|
40,00 × 24,00 × 20,00 cm |
| Zustand / Condition: |
Ungebraucht / Unused |
Product safety information
Manufacturer information:
SEW-EURODRIVE GmbH & Co KG
Ernst-Blickle-Straße 42
Baden-Württemberg
Bruchsal, Deutschland, 76646
sew-webmaster@sew-eurodrive.de
https://www.sew-eurodrive.de/startseite.html
Important Notice!
Our items are generally not new. They come from inventory liquidations and dismantlings.
Please note that for items where no age information is provided in the description, it should be assumed that they have been stored for a very long time, possibly several years. This can affect the quality and durability of technical items. Please consider this before making a purchase.
